P-100-24-ETL
Slim Indoor LED Driver, 100W, 24VDC Constant Voltage, 100-260VAC Input, IP20, ETL
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
- 100W
Ordered by 2,737 customers in the last 24 months
- 100W constant voltage output at 24VDC, 4.16A
- Wide 100-260VAC input range for North American and export use
- Power efficiency rated at 85-90%
- Iron shell enclosure in gray finish, 147 x 50 x 24mm
- IP20 non-waterproof rating for dry indoor locations
- ETL listed with 2-year warranty
At a glance
- Operating Voltage
- 100–260 V
- IP rating
- IP20
- Product Dimensions
- 145x48x24mm
- Maximum Current
- 4.16 A
- Power Supply Input
- 100-260VAC
- Finish
- Gray
Some technical details are being checked. Confirm requirements before choosing connected components.
Datasheet (PDF)- ETL Listed
- Check delivery costs and freight exceptions
- Confirm Doral pickup readiness
- Ships from Miami, FL
- Check this product's warranty terms
Need volume pricing?
Typical applications
- Cove and architectural lighting coves
- Retail display and casework lighting
- Under-cabinet and millwork installations
- Interior signage cabinets
- Commercial accent lighting runs
Constant voltage, ultra-thin indoor LED driver for 24VDC lighting installations in commercial and architectural spaces where a low-profile enclosure is required behind coves, valances and millwork. The driver accepts 100-260VAC input and delivers 24VDC at up to 100W (4.16A), with power efficiency rated at 85-90%. The iron shell enclosure is finished in gray, carries an IP20 non-waterproof rating for dry indoor use, measures 147 x 50 x 24mm and weighs 0.185 kg. ETL listed. Supplied with a 2-year warranty.
| Electrical | |
|---|---|
| Operating Voltage | 100–260 V |
| Wattage | 100 W |
| Maximum Current | 4.16 A |
| Power Supply Input | 100-260VAC |
| Environmental | |
| IP rating | IP20 |
| Environmental Rating | Non-Waterproof |
| Mechanical | |
|---|---|
| Product Dimensions | 145x48x24mm |
| Finish | Gray |
| Material | Iron Shell |
| Weight | 0.41 lb |
| Compliance | |
| Certifications | ETL |
| Ordering | |
| Warranty | 2 y |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetCustomer reviews
No reviews yet. Be the first to review this product.
