5-LDW2514-BK
Drywall Trimless Aluminum LED Profile, Anodized Black, 68mm Wide, 14mm Height
Ordered by 10 customers in the last 24 months
- 6063-T5 aluminum extrusion for heat sinking and LED protection
- Accommodates LED flexible strips up to 21mm wide
- Milky PC diffuser with 86% light transmission and push-in assembly
- Rated operating temperature range of -50°C to 100°C
- Available in 1m, 2m, 2.5m, 3m and 4m lengths
- Anodized black finish over a 68.4mm overall width
At a glance
Typical applications
- Recessed drywall ceiling coves
- Trimless linear ceiling runs in office interiors
- Retail and showroom perimeter lighting
- Hospitality corridors and lobbies
- Residential soffit and wall wash detailing
The trimless drywall aluminum LED profile mounts flush into drywall assemblies for frameless linear lighting in commercial and residential interiors. Measuring 68.4mm (2.69") wide and 14mm (0.55") tall with an anodized black finish, it accepts LED flexible strips up to 21mm wide. Constructed from 6063-T5 aluminum for heat dissipation and physical protection of the installed strip, the profile is offered in 1m, 2m, 2.5m, 3m and 4m lengths. The push-in milky PC diffuser transmits 86% of the light output with medium coefficient diffusion, producing uniform brightness and reducing visible LED points. Rated operating temperature range is -50°C to 100°C. Covered by a 1-year warranty, with a rated LED lifetime of 50,000 hours.
| Optical | |
|---|---|
| LED Lifetime | 50,000 h |
| Environmental | |
| Ambient Operating Temperature | -50 °C(-58 °F) |
| Ordering | |
| Warranty | 1 y |
| Mechanical | |
|---|---|
| Product Dimensions | 68x14mm |
| Length | 4 m(13.1 ft) |
| Strip Width | 21 mm(0.83 in) |
| Finish | Anodized Black |
| Material | 6063-T5 aluminum |
| Mounting | Recessed trimless drywall |
Full manufacturer specifications, dimensions and wiring detail.
