C-SC-BC-144W
Single-Color RF LED Controller, 12-24V, 6A
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
- 24V
- 144W
Purchased in 478 fulfilled orders over the last 24 months
- Constant voltage output rated 144 W at 12-24 V DC
- Maximum output current of 6 A on a single channel
- 4096-level logarithmic dimming across a 0.1% to 100% range
- 2.4 GHz RF control at up to 30 m with auto-forwarding between units
- Bare male and female DC connectors accept 0.5-4.0 mm2 conductors
- IP20 white housing measuring 76 x 19 x 8.8 mm, CE marked
At a glance
- IP rating
- IP20
- Product Dimensions
- 76x19x8.8 mm
- Maximum Current
- 6 A
- Dimmable
- Yes
- Selectable CCT
- Single Color
- Dimmer Type
- 0 - 10V
Some technical details are being checked. Confirm requirements before choosing connected components.
Datasheet (PDF)- CE
- Check delivery costs and freight exceptions
- Confirm Doral pickup readiness
- Ships from Miami, FL
- Check this product's warranty terms
Need volume pricing?
Typical applications
- Cove and perimeter lighting circuits
- Illuminated signage cabinets
- Retail display and casework lighting
- Architectural accent strip runs
- Hospitality guest room lighting
A compact single-channel constant-voltage controller for single color low voltage LED strip and module runs. The 76 x 19 x 8.8 mm housing fits inside extrusions, coves and signage cabinets, and bare DC male and female connectors on the input and output simplify inline connection to existing leads. Input is DC 12-24 V with a maximum output current of 6 A and output power up to 144 W. Dimming uses 4096 discrete levels on a logarithmic curve across a 0.1% to 100% range, with switchable high and low frequency PWM output. Control is 2.4 GHz RF at up to 30 m, with signal auto-forwarding between controllers, do-not-disturb operation after power interruptions, and pairing of up to 12 compatible remotes per controller. Rated IP20 for dry interior locations, with a working temperature range of -10 to 40 C. CE marked and covered by a 5-year warranty.
| Optical | |
|---|---|
| Selectable CCT | Single Color |
| Mechanical | |
| Product Dimensions | 76x19x8.8 mm |
| Finish | White |
| Environmental | |
| IP rating | IP20 |
| Environmental Rating | Non-Waterproof |
| Ambient Operating Temperature | -10–40 °C(14–104 °F) |
| Ordering | |
| Warranty | 5 y |
| Electrical | |
|---|---|
| Operating Voltage | 24 V |
| Wattage | 144 W |
| Maximum Current | 6 A |
| Dimmable | Yes |
| Dimmer Type | 0 - 10V |
| Input Connection Type | Bare male and female DC connectors |
| Compliance | |
| Certifications | CE, EMC, RED |
Full manufacturer specifications, dimensions and wiring detail.
