Single Channel RF LED Controller, 12 VDC, 144 W, 433 MHz Wireless Remote

The C-1-R144 is a single-channel RF controller for wireless brightness control of single-color low-voltage LED loads, including LED strip, LED source modules, wall washers and glass curtain lighting. Wiring uses 5.5 x 2.1 mm DC connectors on both the power input and the load output, with common-anode connection. The controller operates at 12 VDC and handles loads up to 144 W, drawing 4 A. Control is by 433 MHz remote with one-to-one pairing, offering 10 static brightness levels plus 8 dynamic modes such as breathing, strobe, alternating flash and automatic fade. Static power consumption stays below 0.5 W. The white aluminum and plastic housing is rated IP20 for dry interior locations and is listed for -20 to 40 degrees C ambient. CE and RoHS compliant, backed by a 1-year warranty.
