E-DC-P5.5
DC Power Plug Connector, Male 5.5 mm Barrel, 2.1 mm ID, Screw Terminal, 5-Pack
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
- 12V
Ordered by 219 customers in the last 24 months
- Male barrel plug with 5.5 mm external diameter
- 2.1 mm internal plug diameter for standard DC jacks
- Screw-clamp terminals eliminate splicing, crimping and soldering
- Housing measures 39 mm L x 13 mm W x 12 mm H
- Field-terminated with a small screwdriver
- Packaged five pieces per bag with 1-year warranty
At a glance
- Product Dimensions
- 1 x 5.5mm
- Input Connection Type
- Screw terminal
- Warranty
- 1 y
Some technical details are being checked. Confirm requirements before choosing connected components.
Datasheet (PDF)- Check delivery costs and freight exceptions
- Confirm Doral pickup readiness
- Ships from Miami, FL
- Check this product's warranty terms
Need volume pricing?
Typical applications
- CCTV camera power drops
- 12 V LED lighting circuits
- Low-voltage control panels
- Security and access control cabinets
- Small appliance and DC device power leads
A male 5.5 mm DC barrel plug used to terminate low-voltage cable runs feeding 12 V DC equipment. Typical uses include LED lighting circuits, CCTV camera drops, and small appliances or charging devices that accept a standard 5.5 mm DC plug. The plug carries a 5.5 mm external and 2.1 mm internal barrel diameter and terminates conductors with an internal screw clamp, so no soldering, crimping, or electrical tape is required at the connection point. The housing measures 39 mm long by 13 mm wide by 12 mm high and is supplied five pieces per bag. Covered by a 1-year warranty.
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Input Connection Type | Screw terminal |
| Mechanical | |
|---|---|
| Product Dimensions | 1 x 5.5mm |
| Ordering | |
| Warranty | 1 y |
