P-LT72
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Ordered by 97 customers in the last 24 months
Need volume pricing?
A laptop-style tabletop AC/DC power supply that converts universal 100-240V AC line input to a regulated 12V DC output. The external plastic housing suits LED lighting, signage and low-voltage control loads where the supply is mounted outside the fixture or enclosure. Rated output is 72W continuous at 12V DC, up to 6A. The unit operates on single-phase input at 47-63Hz and includes over-current and short-circuit protection with auto-recovery. The case resin carries a V-0 or V-2 flame rating, the enclosure is rated IP20 non-waterproof, and the ambient operating range is -30°C to 50°C. The supply is ETL listed under UL file number 5024093, carries CE and FCC marks, and is RoHS compliant. Covered by a one-year warranty.
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Wattage | 72 W |
| Maximum Current | 60 A |
| Power Supply Input | 100 - 240VAC |
| Power Supply Output | 12VDC |
| Compliance | |
| Certifications | CE, Rosh, FCC, ETL |
| UL File Number | 5024093 |
| Ordering | |
| Warranty | 1 y |
| Mechanical | |
|---|---|
| Product Dimensions | 61x140x34 mm |
| Finish | Black |
| Material | Plastic |
| Weight | 0.51 lb |
| Environmental | |
| IP rating | IP20 |
| Environmental Rating | Non-Waterproof |
| Ambient Operating Temperature | -30–50 °C(-22–122 °F) |
Full manufacturer specifications, dimensions and wiring detail.
