A-BL5.75-S9W
5-3/4 in. Square LED Ceiling Light, 9W Dual-Zone White and Blue Border, 4500K
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
- 9W
- 4,500K
Ordered by 24 customers in the last 24 months
- Dual-zone design: 6W white center plus 3W blue border
- Delivers 675 lm at 4500K with 75 CRI
- 110° beam angle for broad, even light distribution
- Acrylic and aluminum construction rated IP20
Typical applications
- Residential ceiling installations
- Commercial hallway and lobby lighting
- Retail accent lighting
- Hospitality ambient lighting
- Kitchen and bathroom recessed lighting
The A-BL5.75-S9W is a 5-3/4 in. square LED ceiling light for flush-mount installation in residential and commercial applications. Its dual-zone configuration combines a 6W white center with a 3W blue border, fitting into a 4-3/4 in. rough opening. The fixture draws 9W total and outputs 675 lm at 4500K with a CRI of 75 and a 110° beam angle, yielding 75 lm/W efficacy. It operates on 120-240V AC input and is rated IP20 for standard indoor environments, with an ambient operating range of -30 to 50°C. Acrylic and aluminum construction supports an LED lifetime of 50,000 hours. The fixture carries a 2-year warranty.
| Optical | |
|---|---|
| Luminous flux | 675 lm |
| Efficacy | 75 lm/W |
| CCT | 4,500 K |
| CRI | 75 |
| Beam angle | 110° |
| LED Chip Type | SMD2835 |
| LED Lifetime | 50,000 h |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | -30–50 °C(-22–122 °F) |
| Electrical | |
|---|---|
| Operating Voltage | 120–240 V |
| Wattage | 9 W |
| Mechanical | |
| Product Dimensions | 6.45 × 2 × 6.25 in |
| Finish | White |
| Material | acrylic+aluminum |
| Weight | 0.2 lb |
| Ordering | |
| Warranty | 2 y |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetCustomer reviews
