A-BL4-S5W
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Ordered by 17 customers in the last 24 months
The A-BL4-S5W is a 4-inch square recessed ceiling light combining a 3W white light source with a 2W blue decorative border. Designed for residential, commercial, and hospitality applications, it fits an 83mm (3¼-inch) cutout and integrates into modern interior ceilings where task illumination and accent lighting are both desired. The fixture draws 5W total and operates across a 120-240V input range. It uses an acrylic lens with an aluminum housing and SMD2835 chip technology, delivering 375 lumens at 4000K with a CRI of 75 and a 110° beam angle. The IP20 rating suits dry indoor environments, and the fixture is rated for ambient temperatures from -30 to 50°C. This final-sale product has a 30-day limited warranty.
| Optical | |
|---|---|
| Luminous flux | 375 lm |
| Efficacy | 75 lm/W |
| CCT | 4,000 K |
| CRI | 75 |
| Beam angle | 110° |
| LED Chip Type | SMD2835 |
| LED Lifetime | 50,000 h |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | -30–50 °C(-22–122 °F) |
| Electrical | |
|---|---|
| Operating Voltage | 120–240 V |
| Wattage | 5 W |
| Mechanical | |
| Product Dimensions | 5.25 × 1.5 × 5 ft |
| Finish | White |
| Material | acrylic+aluminum |
| Weight | 0.15 lb |
| Ordering | |
| Warranty | 30 days |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetNo reviews yet. Be the first to review this product.
Need volume pricing? Ask about wholesale
Total for 1 item
$10.26
