5-LW1707A
25x7mm Recessed LED Aluminum Channel, 2.5m
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Purchased in 890 fulfilled orders over the last 24 months
- Extruded 6063-T5 aluminum body with anodized surface finish
- 25 x 7 mm profile with 12.5 mm inner channel for strips up to 12 mm
- 2.5 m (98 in) standard length, recessed mounting clips and end caps included
- UV-resistant Bayer PC and PMMA diffusers in four optical grades
- 14.4 W/m and 1,555 lm/m at 12 V DC, 6500 K, CRI 80
- Rated LED life exceeding 50,000 hours
At a glance
- Product Dimensions
- 25x7mm
- Length
- 2.5 m
- Material
- 6063-T5 aluminum
- Warranty
- 1 y
- LED Chip Type
- 2835 SMD
- LEDs per Segment
- 3
Some technical details are being checked. Confirm requirements before choosing connected components.
Datasheet (PDF)- Check delivery costs and freight exceptions
- Confirm Doral pickup readiness
- Ships from Miami, FL
- Check this product's warranty terms
Need volume pricing?
Typical applications
- Cove and ceiling recesses
- Retail display millwork
- Office and corridor linear lighting
- Cabinetry and shelving details
- Hospitality architectural accents
The 5-LW1707A is a recessed-mount aluminum channel profile that houses and protects LED flexible strip lighting in architectural coves, millwork and ceiling details. It is extruded from 6063-T5 aluminum with an anodized surface and measures 25 x 7 mm in cross-section with a 12.5 mm inner channel, accepting flexible strips up to 12 mm wide. Standard length is 2.5 m (98 in). Finishes include silver anodized, white painted and black anodized. The extrusion acts as a heat sink and mechanical shield for the strip. Diffusers in transparent, milky/opal, matt opal and black are fabricated from UV-resistant Bayer PC and PMMA. Paired with the BF2835 12 V DC strip, the assembly delivers 14.4 W and 1,555 lm per meter at 6500 K with CRI 80, a 50 mm minimum cut unit of 3 LEDs, and a rated life above 50,000 hours. Covered by a 1-year warranty.
| Optical | |
|---|---|
| LED Chip Type | 2835 SMD |
| LEDs per Segment | 3 |
| Environmental | |
| IP rating | IP20 / IP65 |
| Ordering | |
| Warranty | 1 y |
| Mechanical | |
|---|---|
| Product Dimensions | 25x7mm |
| Length | 2.5 m(8.2 ft) |
| Strip Width | 12 mm(0.47 in) |
| Finish | Silver anodized, white painted, or black anodized |
| Material | 6063-T5 aluminum |
| Mounting | Recessed |
