Conector de Presión 2-4 puertos, 400V, 32A, Entrada: 20AWG - 10AWG (0.5 - 6mm2), Salida: 28AWG - 12AWG (0.5 - 4mm2)

Name: Conector de Presión 2-4 puertos, 400V, 32A, Entrada: 20AWG - 10AWG (0.5 - 6mm2), Salida: 28AWG - 12AWG (0.5 - 4mm2)
Brand: PoliLED
SKU: E-CON-P-24
Price: 6.50 USD
Availability: InStock

USD 6.50

Disponible — 109 disponibles

Pedido por 37 clientes en los últimos 24 meses

400V voltage rating with 32A current capacity
Accepts 20–10 AWG (0.5–6mm²) input conductors
Accepts 28–12 AWG (0.5–4mm²) output conductors
Polycarbonate housing with nickel-chromium alloy steel spring
Ambient operating range of -40°C to +105°C
8–12mm strip length for tool-free press-on termination

De un vistazo

LED Lifetime: 50,000 h
Operating Voltage: 400 V
Maximum Current: 32 A
Input Connection Type: Press-on spring clamp, 2–4 port
Wire Gauge: 20-10 input, 28-12 output
Material: Polycarbonate housing, nickel-chromium alloy steel spring

Ficha técnica (PDF)

Envío gratis en pedidos de más de $300
Retiro el mismo día en Doral
Envíos desde Miami, FL
Garantía del fabricante incluida

¿Necesita precio por volumen? Consultar mayoreo

Aplicaciones típicas

Fixture and luminaire wiring
Branch circuit junction boxes
Panel and distribution terminations
Sign and display wiring
Retrofit and maintenance splicing

The E-CON-P-24 is a 2–4 port press-on wire connector for fast, tool-free terminations in commercial and industrial wiring. The spring-clamp mechanism accepts a range of conductor sizes, making it suitable for branch circuit connections, fixture wiring, and panel distribution work. The connector is rated for 400V and 32A. Input conductors range from 20–10 AWG (0.5–6mm²) and output conductors from 28–12 AWG (0.5–4mm²). A polycarbonate housing with nickel-chromium alloy steel spring contacts supports an ambient operating range of -40°C to +105°C. Recommended strip length is 8–12mm. Supplied 5 pieces per bag.

Óptica
Vida útil del LED	50,000 h
Mecánica
Material	Polycarbonate housing, nickel-chromium alloy steel spring
Ambiental
Temperatura ambiente de operación	-40–105 °C(-40–221 °F)

Eléctrica
Voltaje de operación	400 V
Corriente máxima	32 A
Tipo de conexión de entrada	Press-on spring clamp, 2–4 port
Calibre del cable	20-10 input, 28-12 output
