E-CON-P-212
Conector de Presión 2-12 puertos, 400V, 32A, Entrada: 20AWG - 10AWG (0.5 - 6mm2), Salida: 28AWG - 12AWG (0.5 - 4mm2)
Pedido por 67 clientes en los últimos 24 meses
- Rated 400V, 32A for commercial and industrial branch circuits
- Input conductor range of 20–10 AWG (0.5–6 mm²)
- Output conductor range of 28–12 AWG (0.5–4 mm²)
- Polycarbonate housing with nickel-chromium alloy steel spring
- Operating temperature range of -40°C to +105°C
- Screwless press-on clamp with 8–12 mm strip length
De un vistazo
- LED Lifetime
- 50,000 h
- Operating Voltage
- 400 V
- Maximum Current
- 32 A
- Wire Gauge
- 20-10 input, 28-12 output
- Material
- Polycarbonate housing, nickel-chromium alloy steel spring
- Ambient Operating Temperature
- -40–105 °C
- Envío gratis en pedidos de más de $300
- Retiro el mismo día en Doral
- Envíos desde Miami, FL
- Garantía del fabricante incluida
¿Necesita precio por volumen? Consultar mayoreo
Aplicaciones típicas
- Lighting fixture wiring
- Branch circuit distribution
- Electrical panel terminations
- Junction box splices
- Control and equipment enclosures
The E-CON-P-212 is a press-on wire connector supporting 2 to 12 ports for tool-free electrical connections in commercial and industrial wiring. The screwless spring-clamp mechanism accepts a range of conductor sizes, suiting branch circuit distribution, lighting fixture wiring, and panel-level terminations where installation speed matters. The connector is rated for 400V and 32A, with an input wire range of 20–10 AWG (0.5–6 mm²) and an output wire range of 28–12 AWG (0.5–4 mm²). The housing is polycarbonate and the internal spring is nickel-chromium alloy steel. Operating temperature range is -40°C to +105°C, with a recommended conductor strip length of 8–12 mm.
| Óptica | |
|---|---|
| Vida útil del LED | 50,000 h |
| Mecánica | |
| Material | Polycarbonate housing, nickel-chromium alloy steel spring |
| Ambiental | |
| Temperatura ambiente de operación | -40–105 °C(-40–221 °F) |
| Eléctrica | |
|---|---|
| Voltaje de operación | 400 V |
| Corriente máxima | 32 A |
| Calibre del cable | 20-10 input, 28-12 output |
Especificaciones completas del fabricante, dimensiones y detalle de conexión.
