E-CON-P-210
Press-On Wire Connector, 2-10 Port, 400V 32A, 20-10 AWG Input, Polycarbonate Housing
USD 9.44
Disponible — 425 disponibles
- Rated 400V, 32A for commercial and industrial branch wiring
- Accepts 2 to 10 ports for multi-conductor terminations
- Input wire range 20-10 AWG (0.5-6 mm2)
- Output wire range 28-12 AWG (0.5-4 mm2)
- Polycarbonate housing with nickel-chromium alloy steel spring contact
- Operates from -40 C to +105 C with 8-12 mm stripped length
- Retiro el mismo día en Doral
- Envíos desde Miami, FL
- Garantía del fabricante incluida
A press-on wire connector supporting 2 to 10 ports, designed for tool-free electrical connections in commercial and industrial wiring. It suits junction and distribution points where multiple conductors must be terminated without crimping or screw-down hardware. The connector is rated for 400V and 32A, with an input wire range of 20-10 AWG (0.5-6 mm2) and an output wire range of 28-12 AWG (0.5-4 mm2). The grey housing is polycarbonate and the internal spring contact is nickel-chromium alloy steel. Ambient operating range is -40 C to +105 C, with a stripped wire length of 8-12 mm for termination.
