SKU: P-S200-UL
The P-S200-UL is a constant voltage LED power supply designed for outdoor and indoor installations requiring a stable 12VDC output. It is suited for LED lighting systems, security cameras, and other electrical equipment operating in wet, dry, or rainy environments. The unit delivers up to 200W at 12VDC (±0.5VDC) with a maximum output current of 16.7A. Input is rated for 100–130VAC at 50/60Hz, with a typical efficiency of 89% and no-load power consumption under 3W. Operating temperature range is -30°C to 50°C. Protections include short circuit, overload, overvoltage, and overtemperature, all with automatic recovery after fault clearance. The power supply carries an IP67 rating, confirming full dust protection and resistance to temporary water immersion. The UL Listed designation is referenced in the product description. A 3-year warranty is included.
