P-S100-UL
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Ordered by 52 customers in the last 24 months
The P-S100-UL is a 100W outdoor-rated LED power supply designed for commercial and landscape lighting installations requiring a stable 12VDC output. Its weatherproof aluminum construction supports permanent exterior mounting in demanding environments. The unit delivers 100W at 12VDC with a current draw of 8.3A. It accepts an AC input range of 90-130V, accommodating standard 120VAC circuits without additional conversion hardware. An IP67 rating provides protection against dust ingress and water immersion, supporting reliable operation across an ambient temperature range of -30°C to 50°C. The black aluminum housing measures 7 x 2.5 x 0.75 in. and weighs 1.1 lb. This power supply is UL Listed and carries a 3-year warranty.
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Wattage | 100 W |
| Maximum Current | 8.3 A |
| Power Supply Input | 90 - 130VAC |
| Power Supply Output | 12VDC |
| Compliance | |
| Certifications | UL |
| Ordering | |
| Warranty | 3 y |
| Mechanical | |
|---|---|
| Product Dimensions | 18.2*6.3*1.85cm |
| Finish | Black |
| Material | Aluminum |
| Weight | 1.1 lb |
| Environmental | |
| IP rating | IP67 |
| Ambient Operating Temperature | -30–50 °C(-22–122 °F) |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetNo reviews yet. Be the first to review this product.
Need volume pricing? Ask about wholesale
Total for 1 item
$64.66
Based on real order history
Order history does not verify compatibility. Check voltage, strip width, pins and load before selecting parts.
