P-60-D
60W 12V DC Dimmable LED Driver, 5-in-1 Dimming, Triac & 0-10V, IP20
- 12V
- 60W
- 5-in-1 dimming: 0-10V, 1-10V, 10V PWM, Triac and Resistance
- Regulated 12VDC ±0.5V output rated to a maximum of 5A
- Typical efficiency of 86% with output ripple held to ≤200mV
- Aluminum alloy enclosure, 145 × 48 × 29mm, metallic silver finish
- Ambient rating of -30°C to 50°C with free air convection cooling
- CE marked to IEC/EN61347-1 and IEC/EN61347-2-13, 3-year warranty
- Same-day pickup in Doral
- Ships from Miami, FL
- Manufacturer warranty included
The P-60-D is a 60W, 12V DC constant-voltage LED driver for indoor installations. It supports 5-in-1 dimming — 0-10V, 1-10V, 10V PWM, Triac and Resistance — across a 0-100% range with LED start possible at 1%. Rated IP20, it is intended for dry interiors and cools by free air convection. Input is 175-264Vac or 100-130Vac at 50/60Hz, with a regulated 12VDC ±0.5V output at up to 5A and typical efficiency of 86%. Ambient operating range is -30°C to 50°C at 20-95% RH non-condensing. Output ripple is ≤200mV, and overload, dual-level short-circuit, over-voltage and over-temperature protections are included. The aluminum alloy housing measures 145 × 48 × 29mm in a metallic silver finish and weighs approximately 160g. The driver is CE marked, built to IEC/EN61347-1 and IEC/EN61347-2-13 safety standards, and carries a 3-year warranty.
