P-100-D
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Ordered by 141 customers in the last 24 months
The Lumipro P-100-D is a 12V DC dimmable LED power supply designed for indoor LED lighting installations in residential, commercial, and industrial applications. Its compact form factor supports integration into lighting control systems requiring Triac or 0-10V dimming, and it is compatible with Lutron and other standard dimmer switch brands. The unit delivers a maximum output of 100W at 12V DC with a rated output current of 8.3A, accepting a 90-130VAC input range. It carries an IP20 rating for protected indoor environments and an aluminum alloy housing rated for ambient operation from -30 to 50°C. The P-100-D carries a 3-year warranty and is CE certified.
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Wattage | 100 W |
| Maximum Current | 8.3 A |
| Dimmable | Yes |
| Dimmer Type | Triac + 0-10V |
| Power Supply Input | 90 - 130VAC |
| Power Supply Output | 12VDC |
| Compliance | |
| Certifications | CE |
| Mechanical | |
|---|---|
| Product Dimensions | 16*4.8*2.9cm |
| Finish | Metallic Silver |
| Material | Aluminum Alloy |
| Weight | 0.6 lb |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | -30–50 °C(-22–122 °F) |
| Ordering | |
| Warranty | 3 y |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetNo reviews yet. Be the first to review this product.
Need volume pricing? Ask about wholesale
Total for 1 item
$45.58
Based on real order history
Order history does not verify compatibility. Check voltage, strip width, pins and load before selecting parts.
