P-100-D
100W 12V DC Dimmable LED Power Supply, Triac and 0-10V, 120VAC Input
- 12V
- 100W
Ordered by 139 customers in the last 24 months
- Delivers 100W maximum output at 12V DC, 8.3A rated current
- Accepts 90-130VAC input for standard indoor electrical systems
- Supports Triac and 0-10V dimming, compatible with Lutron dimmers
- IP20 rated aluminum alloy housing in metallic silver finish
- Rated for ambient operation from -30°C to 50°C
- Backed by a 3-year manufacturer warranty
At a glance
- Dimmable
- Yes
- Operating Voltage
- 12 V
- Wattage
- 100 W
- Maximum Current
- 8.3 A
- Dimmer Type
- Triac + 0-10V
- Power Supply Input
- 90 - 130VAC
- CE
- Free shipping on orders over $300
- Same-day pickup in Doral
- Ships from Miami, FL
- Manufacturer warranty included
Need volume pricing? Ask about wholesale
Typical applications
- Residential LED lighting installations
- Commercial retail and office lighting
- Industrial indoor lighting systems
- Dimmable LED strip and fixture power supply
The Lumipro P-100-D is a 12V DC dimmable LED power supply designed for indoor LED lighting installations in residential, commercial, and industrial applications. Its compact form factor supports integration into lighting control systems requiring Triac or 0-10V dimming, and it is compatible with Lutron and other standard dimmer switch brands. The unit delivers a maximum output of 100W at 12V DC with a rated output current of 8.3A, accepting a 90-130VAC input range. It carries an IP20 rating for protected indoor environments and an aluminum alloy housing rated for ambient operation from -30 to 50°C. The P-100-D carries a 3-year warranty and is CE certified.
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Wattage | 100 W |
| Maximum Current | 8.3 A |
| Dimmable | Yes |
| Dimmer Type | Triac + 0-10V |
| Power Supply Input | 90 - 130VAC |
| Power Supply Output | 12VDC |
| Compliance | |
| Certifications | CE |
| Mechanical | |
|---|---|
| Product Dimensions | 16*4.8*2.9cm |
| Finish | Metallic Silver |
| Material | Aluminum Alloy |
| Weight | 0.6 lb |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | -30–50 °C(-22–122 °F) |
| Ordering | |
| Warranty | 3 y |
Full manufacturer specifications, dimensions and wiring detail.
