P-200
200W 12V DC LED Power Supply, 170–265VAC Input, Indoor Rated
- 200W
Ordered by 21 customers in the last 24 months
At a glance
- Operating Voltage
- 170-265VAC
- Wattage
- 200 W
- Product Dimensions
- 178 x 50 x 23
- Weight
- 0.25 kg
- Ambient Operating Temperature
- -10 to +50
- Warranty
- 3 years
The Poli P-200 is a 200W, 12V DC LED power supply designed for indoor LED lighting installations. It accepts a wide AC input range of 170–265VAC at 50–60Hz, making it suitable for use across varying supply conditions. A built-in DC ball bearing fan provides forced-air cooling for continuous operation. The unit delivers a rated output of 13A at 12VDC with a ripple and noise ceiling of 180mV. Operating temperature range is -10°C to +50°C. Protections include short circuit, overload (hiccup mode, auto-recovery), and overvoltage, all with automatic recovery upon fault clearance. Efficiency is rated at greater than 87% at full load. The power supply carries a 3-year warranty and has undergone 100% full-load burn-in testing. This product is RoHS compliant. EMC emission compliance is per EN55032 (CISPR32) Class B, and safety standards include UL62368-1 and TUV EN62368-1 approval per the source datasheet.
| Electrical | |
|---|---|
| Operating Voltage | 170-265VAC |
| Wattage | 200 W |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | -10 to +50 |
| Mechanical | |
|---|---|
| Product Dimensions | 178 x 50 x 23 |
| Weight | 0.25 kg |
| Ordering | |
| Warranty | 3 years |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetCustomer reviews
