SKU: P-100S
The P-100S is a slim-profile, constant-voltage LED switching power supply rated at 100W with a 12VDC output. Designed exclusively for indoor installations, it is suited for LED lighting systems in commercial and architectural applications requiring a stable, low-voltage DC source. The unit delivers up to 8.5A at 12VDC (±0.5V) with a typical efficiency of 88% and a power factor greater than 0.6 at 230Vac. It accepts a dual input range of 175–264Vac or 100–130Vac at 50/60Hz and operates across an ambient temperature range of -30°C to 50°C. Built-in protections cover short circuit, overload, overvoltage, and overtemperature conditions, all with automatic recovery. The enclosure carries an IP20 rating and is cooled by free air convection. Each unit undergoes 100% full-load burn-in testing at a minimum of 40°C for four hours. The P-100S is certified to IEC/EN61347 and IEC/EN60950 safety standards and complies with EMC standards EN55015:2013, EN61547:2009, EN61000-3-2:2014, and EN61000-3-3:2013. A CB mark is confirmed in the source documentation. No warranty term is specified in the available source data; consult your Poli LED & Signs representative for current warranty terms.
