M-C-SPI-360-6K-24V-UL
COB SPI Digital LED Strip, WS2811, 360 LEDs/m, 12 W/m, 6000 K, IP20, 24 V DC, 5 m Reel
Each unit contains 5 m, according to this product’s current specifications. Quantity selects the number of units.
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
- 24V
- 6,000K
- 10mm
Ordered by 54 customers in the last 24 months
- 360 COB chips per meter for dot-free continuous illumination
- WS2811 addressable ICs for sequential running-water effects
- 750 lm per meter at 12 W per meter, CRI above 90
- 180-degree beam angle on a 10 mm double-layer 2 oz PCB
- 5 m reel with 83.33 mm minimum cut increment
- UL, CE and RoHS approved, UL file E539769
At a glance
- CRI
- 90
- IP rating
- IP20
- LED Density
- 360 LEDs/m
- Length
- 5 m
- Minimum Cut Length
- 83.33 mm
- Product Dimensions
- 5000x10x4 mm
Some technical details are being checked. Confirm requirements before choosing connected components.
Datasheet (PDF)- RoHS Compliant
- UL Listed
- CE
- Check delivery costs and freight exceptions
- Confirm Doral pickup readiness
- Ships from Miami, FL
- Check this product's warranty terms
Need volume pricing?
Typical applications
- Architectural cove and reveal lighting
- Retail display casework
- Commercial millwork and shelving accents
- Hospitality feature walls
- Signage and channel letter backlighting
This addressable COB LED strip uses WS2811 control ICs to produce sequential running-water effects in a single 6000 K color. The 10 mm double-layer 2 oz PCB and 4 mm profile suit coves, reveals, display casework and architectural accent runs in dry interior locations. Continuous COB emitters at 360 chips per meter deliver 750 lm/m at 12 W/m with a 180-degree beam angle and CRI above 90, minimizing visible dotting. The strip ships on 5 m reels, cuts at 83.33 mm increments, carries an IP20 non-waterproof rating and operates from -25 C to +45 C on 24 V DC. UL, CE and RoHS approved, under UL file E539769, with a 3-year warranty.
| Optical | |
|---|---|
| CCT | 6,000 K |
| Selectable CCT | Single Color |
| CRI | 90 |
| Beam angle | 180° |
| LED Chip Type | COB |
| LED Density | 360 LEDs/m |
| LED Lifetime | 26,280 h |
| Color | White |
| Environmental | |
| IP rating | IP20 |
| Environmental Rating | Non-Waterproof |
| Ambient Operating Temperature | -25 °C(-13 °F) |
| Electrical | |
|---|---|
| Operating Voltage | 24 V |
| Mechanical | |
| Product Dimensions | 5000x10x4 mm |
| Length | 5 m(16.4 ft) |
| Strip Width | 10 mm(0.39 in) |
| Minimum Cut Length | 83.33 mm(3.28 in) |
| Finish | White |
| Weight | 0.29 lb |
| Compliance | |
| Certifications | UL, CE, Rosh |
| UL File Number | E539769 |
| Ordering | |
| Warranty | 3 y |
Full manufacturer specifications, dimensions and wiring detail.
