M-50NB-60-RGB-UL
RGB Bendable LED Strip, SMD5050, 60 LEDs/m, 7.2W/m, 12V DC, IP20, 5m Reel
- 12V
- 7.2W
Ordered by 90 customers in the last 24 months
- SMD5050 RGB chips at 60 LEDs per meter on 8mm flexible PCB
- 7.2W/m draw at 12V DC, 0.6A per meter input current
- 190 lm/m output with a 120-degree emitting angle
- Cuttable every 62.5mm at 12V for field-fit runs
- Double-layer PCB with lead-free SMT assembly, RoHS compliant
Typical applications
- Cove and ceiling recess lighting
- Curved architectural accent details
- Retail display and shelving illumination
- Millwork and cabinet perimeter lighting
- Signage and column wraps
An indoor RGB bendable LED strip built on an 8mm-wide flexible PCB, intended for curved and S-shaped runs where standard rigid or side-cut strips will not conform. SMD5050 chips at 60 per meter suit architectural accent lighting, cove details, and retail display work that requires color changing. The strip operates on 12V DC, drawing 7.2W and 0.6A per meter and delivering 190 lm/m at a 120-degree emitting angle. Rolls are supplied in 5000 x 8mm lengths with a minimum cuttable length of 62.5mm at 12V and a minimum bend radius of 50mm. IP20 construction is rated for dry interior use, with 40% to 70% RH operating humidity, double-layer PCB, lead-free SMT assembly, gold bonding wire, and 3M adhesive backing. Rated LED life is 50,000 hours. Manufactured in compliance with RoHS (lead-free).
| Optical | |
|---|---|
| Luminous flux | 190 lm |
| Luminous Flux per Foot | 57.91 lm/ft |
| Efficacy | 960 lm/W |
| CRI | 90 |
| Beam angle | 120° |
| LED Chip Type | SMD5050 |
| LED Density | 60 LEDs/m |
| LED Lifetime | 50,000 h |
| Color | RGB |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | -40–40 °C(-40–104 °F) |
| Operating Humidity | 40-70% RH |
| Ordering | |
| Warranty | 1 y |
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Wattage | 7.2 W |
| Wattage per Foot | 2.19 W/ft |
| Maximum Current | 0.6 A |
| Current Draw per Foot | 0.18 A/ft |
| Max Run (Class 2) | 45 ft(13.7 m) |
| Input Connection Type | 4-pin wire |
| Mechanical | |
| Product Dimensions | 5000 * 8 mm |
| Length | 5 m(16.4 ft) |
| Strip Width | 8 mm(0.31 in) |
| Minimum Cut Length | 2 mm(0.08 in) |
| Finish | White |
| Material | Flexible PCB (FPC) |
| Mounting | 3M adhesive tape backing |
Calculated from other published specifications.
Maximum run calculated against a 100 W Class 2 limit. Verify against local code and the driver rating.
