M-28NB-60-30K-UL
Out of stock right now. Ask us for the next delivery date.
Each unit contains 5 m, according to this product’s current specifications. Quantity selects the number of units.
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Ordered by 190 customers in the last 24 months
This S-shape bendable LED strip is built for indoor installations that require flexible routing around curves and contoured surfaces. A 6 mm wide flexible PCB carries SMD2835 chips at 60 LEDs per meter, suiting cove lighting, display case illumination and architectural accent work where rigid strip cannot follow the installation path. The strip operates on 12 V DC and draws 0.6 A per meter at 7.2 W per meter, with an efficacy of 100 lm/W, CRI 80 at 3000 K and a 120-degree emitting angle. Minimum cut length is 50 mm on a 5 m roll, and rated LED life is 50,000 hours. Operating range is -20 °C to +45 °C at 40-70% RH, with an IP20 non-waterproof rating for dry interior use. Double-layer PCB construction and 3M adhesive backing support stable electrical performance and direct surface mounting. Manufactured with lead-free SMT processes, RoHS compliant and UL listed under file E346797. A two-year warranty applies.
| Optical | |
|---|---|
| Efficacy | 100 lm/W |
| CCT | 3,000 K |
| Selectable CCT | Single Color |
| CRI | 80 |
| Beam angle | 120° |
| LED Chip Type | SMD 2835 |
| LED Density | 60 LEDs/m |
| LED Lifetime | 50,000 h |
| Environmental | |
| IP rating | IP20 |
| Environmental Rating | Non-Waterproof |
| Ambient Operating Temperature | -20–45 °C(-4–113 °F) |
| Operating Humidity | 40-70% RH |
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Mechanical | |
| Product Dimensions | 5000 * 6 mm |
| Length | 5 m(16.4 ft) |
| Strip Width | 6 mm(0.24 in) |
| Minimum Cut Length | 50 mm(1.97 in) |
| Finish | White |
| Material | PCB |
| Mounting | Wall/Pole Mount |
| Compliance | |
| Certifications | UL |
| UL File Number | E346797 |
| Ordering | |
| Warranty | 2 y |
Full manufacturer specifications, dimensions and wiring detail.
