Connector PlugsDatasheet (PDF)
E-DC-P5.5-5
DC 5.5 x 2.1mm Male Barrel Plug, 5-Inch 20 AWG Lead, 5A at 24V DC
$2.12
In Stock — 90 available
- 24V
Ordered by 24 customers in the last 24 months
- DC 5.5 x 2.1mm barrel geometry for standard low-voltage LED drivers
- 5-inch (15 cm) pigtail lead for short-run panel and junction wiring
- 20 AWG stranded conductor sized for low-voltage LED circuits
- Rated for 5A continuous current at up to 24V DC
- Supplied with a one-year manufacturer warranty
At a glance
- LED Lifetime
- 50,000 h
- Operating Voltage
- 24 V
- Maximum Current
- 5 A
- Input Connection Type
- DC 5.5 x 2.1mm male barrel plug
- Wire Gauge
- 20 AWG
- Wire Length
- 5 in
- Free shipping on orders over $300
- Same-day pickup in Doral
- Ships from Miami, FL
- Manufacturer warranty included
Need volume pricing?
Typical applications
- LED driver terminations
- Low-voltage sign cabinets
- Control panel and junction box wiring
- Under-cabinet and cove lighting runs
- Power supply bench and service replacements
A DC 5.5 x 2.1mm male barrel plug pigtail used to connect LED drivers, power supplies and low-voltage lighting components in commercial and industrial installations. The 5-inch (15 cm) lead suits panel wiring, junction connections and driver terminations where a short flying lead is required. The plug is rated for 5A continuous current at up to 24V DC and terminates 20 AWG stranded conductor, matching common low-voltage LED system wiring practice. Covered by a one-year warranty.
| Optical | |
|---|---|
| LED Lifetime | 50,000 h |
| Mechanical | |
| Product Dimensions | 5.5 * 2.1mm |
| Ordering | |
| Warranty | 1 y |
| Electrical | |
|---|---|
| Operating Voltage | 24 V |
| Maximum Current | 5 A |
| Input Connection Type | DC 5.5 x 2.1mm male barrel plug |
| Wire Gauge | 20 AWG |
| Wire Length | 5 in |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetCustomer reviews
No reviews yet. Be the first to review this product.
