Double Wire Quick Connector, 300V 8A, 0.35–0.75mm² Cable Range, IP20

Name: Double Wire Quick Connector, 300V 8A, 0.35–0.75mm² Cable Range, IP20
SKU: E-CON-2-W
Price: 5.00 USD
Availability: InStock

$5.00

In Stock — 1055 available

Quantity: 1 · Unit: 10 pcs (10pcs)

Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.

Ordered by 40 customers in the last 24 months

Rated 300V and 8A for low-voltage control and lighting circuits
Accepts 0.35–0.75mm² conductors, 1.5mm to 2.1mm cable outer diameter
PC UL94-V0 flame-retardant insulating housing
High-precision brass contacts with copper conductors
Compact 35 x 9.5 x 6mm body for tight enclosures and channels
Operating ambient range of -20°C to +105°C, IP20 rated

At a glance

Operating Voltage: 300 V
IP rating: IP20
Product Dimensions: 35x9.5x6mm
Maximum Current: 8 A
Input Connection Type: Two-conductor quick connect, 0.35–0.75mm² wire range
Material: PC UL94-V0 housing, high-precision brass contacts, copper conductors

Some technical details are being checked. Confirm requirements before choosing connected components.

Datasheet (PDF)

Check delivery costs and freight exceptions
Confirm Doral pickup readiness
Ships from Miami, FL
Check this product's warranty terms

Need volume pricing?

Typical applications

LED strip and module wiring runs
Lighting control and signal wiring
Sign cabinet and channel letter assemblies
Low-voltage junction and enclosure terminations
Fixture retrofit and maintenance splices

The E-CON-2-W is a two-conductor quick-connect wire connector for tool-free splicing in LED lighting installations, control wiring, and general low-voltage electrical assemblies. It accepts conductors in the 0.35–0.75mm² range and provides a compact termination point in a 35 x 9.5 x 6mm body. Rated at 300V and 8A, the connector accommodates cable outer diameters from 1.5mm to 2.1mm. The insulating body is PC UL94-V0 flame-retardant material, and the contact conductor is high-precision brass with copper conductors. Operating ambient temperature range is -20°C to +105°C, with an IP20 enclosure rating. Supplied in bags of 5 pairs.

Electrical
Operating Voltage	300 V
Maximum Current	8 A
Input Connection Type	Two-conductor quick connect, 0.35–0.75mm² wire range

Mechanical
Product Dimensions	35x9.5x6mm
Material	PC UL94-V0 housing, high-precision brass contacts, copper conductors
Environmental
IP rating	IP20
Ambient Operating Temperature	-20–105 °C(-4–221 °F)
