E-6CH-24V-Wifi
6-Channel LED Control Box, 60 W, 12-24 VDC, WiFi, RF and Sensor Dimming, IP20
- 24V
- 60W
Ordered by 113 customers in the last 24 months
- Six synchronous constant-voltage outputs, 2 A maximum per channel
- 60 W maximum total output power at 12 V or 24 V
- WiFi Tuya cloud, RF 2.4G remote and wired sensor head dimming inputs
- 8000 Hz PWM output on a gamma 1.6 dimming curve
- IP20 ultra-thin enclosure, 0.7 x 2.1 x 2.1 in, rated to 45 C ambient
- CE and RoHS compliant with a 5-year, 50,000-hour warranty
At a glance
- Dimmable
- Yes
- LED Lifetime
- 50,000 h
- Operating Voltage
- 24 V
- Wattage
- 60 W
- Maximum Current
- 2 A
- Dimmer Type
- PWM, 8000 Hz (WiFi, RF 2.4G, sensor input)
- CE
- RoHS Compliant
- Free shipping on orders over $300
- Same-day pickup in Doral
- Ships from Miami, FL
- Manufacturer warranty included
Need volume pricing? Ask about wholesale
Typical applications
- Kitchen and vanity cabinet strip lighting
- Closet and wardrobe shelving lighting
- Retail display case and showcase millwork
- Under-counter and toe-kick accent lighting
- Motion-activated pantry and drawer lighting
A six-channel constant-voltage dimming control box for cabinet and millwork LED strip. It accepts 12-24 VDC from a remote power supply and drives single-color strip through six synchronous outputs, with dimming commanded over WiFi (Tuya cloud), RF 2.4G remote, or a wired sensor head input for PIR motion, touch, hand-sweep and door-contact heads. Total output is limited to 60 W at either 12 V or 24 V, with 2 A maximum per channel and an 8000 Hz PWM output following a gamma 1.6 dimming curve. Light on/off fade time is selectable at 3 s, sensor input accepts 5 V level or 500-2000 Hz PWM signals, and the ultra-thin IP20 enclosure measures 0.7 x 2.1 x 2.1 in for concealed installation at 45 C ambient. CE and RoHS compliant, covered by a 5-year, 50,000-hour warranty.
| Optical | |
|---|---|
| LED Lifetime | 50,000 h |
| Mechanical | |
| Product Dimensions | 0.7 × 2.1 × 2.1 in |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | 45 °C(113 °F) |
| Compliance | |
| Certifications | CE ROHS |
| Ordering | |
| Warranty | 5 y |
| Electrical | |
|---|---|
| Operating Voltage | 24 V |
| Wattage | 60 W |
| Maximum Current | 2 A |
| Dimmable | Yes |
| Dimmer Type | PWM, 8000 Hz (WiFi, RF 2.4G, sensor input) |
| Power Supply Input | 12-24 VDC |
| Power Supply Output | 24VDC |
| Input Connection Type | 2P terminal, 3.1 mm foot distance |
Full manufacturer specifications, dimensions and wiring detail.
