B-F1-CF02-WL
WPC Composite Fence Panel, 3.54 in Width, 0.98 in Thickness, Walnut Co-Extruded Finish
Ordered by 2 customers in the last 24 months
- Co-extruded polymer cap over recycled plastic and wood fiber core
- 3.54 in panel width sized for mid-trellis and full-trellis layouts
- Walnut 3D wood grain surface texture with factory-matched color
- Waterproof, UV-protected rating for exterior perimeter use
- 25-year rated service life on the composite panel
- 5.82 lb per panel for single-installer handling
At a glance
- Product Dimensions
Typical applications
- Residential privacy fencing
- Commercial property perimeter screening
- Courtyard and garden trellis screens
- Pool and patio enclosures
- Rooftop terrace screening
The S-CF02 is a co-extruded WPC (Wood Composite Polymer) fence panel in a Walnut finish, 3.54 in wide and 0.98 in thick. It serves as the narrow infill board in mid-trellis and full-trellis fence configurations, installed between aluminum posts, rails, brackets, side covers and caps. The panel is produced by fusing a protective polymer outer layer to a high-density recycled plastic and wood fiber core, yielding a 3D wood grain surface with a waterproof, UV-protected environmental rating and a 25-year rated service life. Each panel weighs 5.82 lb and is secured with L-fix brackets and M4x16 mm stainless screws, with a 4 mm gap held between post and panel. The fence system carries a 10-year warranty.
| Mechanical | |
|---|---|
| Product Dimensions | 10x80mm |
| Finish | Walnut, 3D wood grain |
| Material | WPC (Wood Composite Polymer) |
| Mounting | Aluminum post with L-fix brackets and M4x16 mm screws |
| Weight | 5.82 lb |
| Environmental | |
|---|---|
| Environmental Rating | Waterproof, UV protection |
| Ordering | |
| Warranty | 10 y |
Full manufacturer specifications, dimensions and wiring detail.
