SMD2835 LED Module, 12VDC 1W IP68 Injected, 170° Beam Angle

$16.96

In Stock — 4973 available

12V
1W
IP68

Ordered by 7 customers in the last 24 months

Injected shell housing rated IP68 for dust and water submersion protection
Delivers 44 lm output through a wide 170° beam angle
Operates at 12VDC with 1W power consumption
Uses SMD2835 LED chip technology
Rated for 50,000 hour LED lifetime
Backed by a 1-year manufacturer warranty

At a glance

Efficacy: 44 lm/W
Beam Angle: 170°
Luminous Flux: 44 lm
LED Chip Type: SMD2835
LED Lifetime: 50,000 h
Operating Voltage: 12 V

Datasheet (PDF)

Free shipping on orders over $300
Same-day pickup in Doral
Ships from Miami, FL
Manufacturer warranty included

Need volume pricing? Ask about wholesale

Typical applications

Illuminated channel letters
Backlit signage panels
Indoor display cabinets
Outdoor sign fixtures
Low-profile accent lighting

The 7-28x1W-UL is a compact SMD2835 LED module designed for integration into commercial and industrial lighting assemblies, signage, and both indoor and outdoor fixture applications where a low-profile, submersible light source is required. The module operates at 12VDC with a power draw of 1W and delivers 44 lm through a wide 170° beam angle, supporting broad, even light distribution. Its injected shell construction and IP68 rating provide full protection against dust ingress and continuous water submersion, making it suitable for demanding installation environments. The LED is rated for a 50,000 hour service life. The module is backed by a 1-year warranty.
