PIR Motion Sensor LED Dimmer, 12-48VDC Input, Single Channel, 8A / 384W Max Output

The single-channel sensor LED dimmer interfaces with a range of low-voltage induction sensor heads and drives constant-voltage LED strip directly. Compatible sensor types include PIR motion, touch, door, hand sweep and microwave motion detectors, suiting cabinet lighting, display cases and other low-voltage accent or task lighting. Input and output operate on 12-48VDC constant voltage with up to 8A output current and maximum output power of 384W at 48V (96W/192W/288W/384W at 12V/24V/36V/48V). The white housing measures 33 x 97 x 18 mm, is rated IP20 for indoor dry locations, and functions from -30°C to +55°C ambient with a maximum case temperature of +85°C. The PIR head provides 120° coverage and holds the load on for 30 seconds after the field clears. CE and RoHS compliant, tested to EN 61347-1 and EN IEC 55015 safety and EMC standards, with a 5-year warranty.
