C-SQ32-500
32-Channel Sequential Stair LED Controller, 500W, 12V/24V DC, PIR Sensor, IP20
- 12V
- 500W
- Drives up to 32 individually sequenced stair channels
- 500W maximum load on DC 12V or 24V input and output
- Two PIR sensors with 1 to 3 m range and 120-degree coverage
- Button switch sets channel quantity and five speed levels
- IP20 non-waterproof white housing, 185 x 80 x 20 mm
- CE and RoHS with a 1-year warranty
- Retiro el mismo día en Doral
- Envíos desde Miami, FL
- Garantía del fabricante incluida
A 32-channel sequential stair LED controller for residential, office, and commercial stair lighting. When either of the two PIR motion sensors detects movement, the first step illuminates and the remaining steps follow in turn at the configured speed; when the area clears, the lights switch off in sequence. Channel quantity and speed are set from the onboard button switch, with five selectable speed levels. Input and output are DC 12V or 24V, with a maximum load of 500W across up to 32 channels. Sensor coverage is 1 to 3 meters at a 120-degree detection angle. The housing measures 185 x 80 x 20 mm in a white finish and is rated IP20 non-waterproof for dry indoor use. Input and output are low-voltage DC only, not 110V or 220V AC. CE and RoHS. Warranty: 1 year.
