C-5IN1-WP-4
RF Touch Panel Remote, 4-Zone 2.4GHz Wireless Control, 86 mm Wall-Box Mount
- 0,2W
- 2.4 GHz RF transmission at 6 dBm with 30 m rated control distance
- Four independent lighting zones with individual link and unlink
- Capacitive touch slider dims linked fixtures from 1 to 100 percent
- 0.15 W standby power draw on AC 100-240 V input
- 86 x 86 mm panel mounts to a standard wall box
- 60-second delay-off function with audible touch confirmation
- Retiro el mismo día en Doral
- Envíos desde Miami, FL
- Garantía del fabricante incluida
A 2.4 GHz RF capacitive touch panel remote for zone-based control of compatible LED lighting, LED controllers and smart panel controllers. Four independent zones can be linked and unlinked individually, making it suited to commercial and residential lighting layouts managed from a single wall-mounted interface. The T series accepts AC 100-240 V with a 0.15 W standby draw, while the B series variant runs on 3 V from two AAA cells. Both transmit at 6 dBm over 2.4 GHz with a rated control distance of 30 m and operate from -10 to 40 °C. Functions include per-zone on/off, master on/off, dimming from 1 to 100 percent, 60-second delay-off and audible touch confirmation toggled by a 5-second press. The 86 x 86 mm panel fits a standard wall box. Supplied with a 1-year warranty.
