5-in-1 LED Strip Controller, 2.4GHz RF, 24V DC, 15A Total Output

The C-5IN1-180-15A is a 5-in-1 low voltage LED strip controller for single-color, dual-white, RGB, RGBW, and RGB+CCT strip configurations. Output mode is selected by pressing the front-panel SET button, with the active mode identified by indicator color. It suits cove, display, and signage installations where one controller stock item must cover several strip types. The controller runs on 24 V DC with a maximum total output of 15 A and operates in ambient temperatures from -10 to 40 °C. 2.4GHz RF remote control reaches 30 m, and auto-transmitting lets one unit relay remote signals to another within that range, while linked units synchronize dynamic modes. Brightness, saturation, and color temperature are adjustable across 16 million color selections, with switchable PWM frequency, a Do Not Disturb power-state memory, DMX512 input in RGB+CCT mode via a separate FUTD01 transmitter, and smartphone or voice control through a 2.4GHz gateway. Rated LED lifetime is 50,000 hours. Certified to CE and RoHS and covered by a 1-year warranty.
