RF Touch Wall Remote, 2-Channel 4-Zone Battery-Powered, 2.4GHz Wireless

The C-5IN1-WP-2 is a 2.4GHz capacitive touch panel remote designed for zone-based control of compatible LED lighting systems and controllers. Operating across 4 independent zones, it supports linking and unlinking of fixtures, master on/off, 60-second delay-off, and brightness adjustment via touch slider. The B series variant is battery-powered (2×AAA, 3V), while the T series connects to AC 100–240V mains. Both share a 2.4GHz RF transmission frequency, 6dBm transmitting power, and a rated control distance of 30 meters. The remote operates within a temperature range of -10°C to 40°C (14°F to 104°F) and measures 86×86mm in footprint. Standby power consumption is 20µA for the battery-powered B series and 0.15W for the AC-powered T series.
