C-VTG-SW2-AB
2-Gang 3-Way Brass Toggle Switch, 120V AC, 150W Per Switch, Night Black
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Purchased in 1 fulfilled orders over the last 24 months
- 2-gang, 3-way toggle configuration for multi-location control
- Brass plate in an all-black vintage finish, 120mm x 120mm
- 150W maximum load per switch on 120V AC circuits
- Rated 15 A with an IP20, non-waterproof environmental rating
- UL Listed under file number E481372-20200313
- 50,000-hour rated life with a 1-year warranty
At a glance
- Operating Voltage
- 120 V
- IP rating
- IP20
- Product Dimensions
- 120mm*120mm
- Maximum Current
- 15 A
- LED Lifetime
- 50,000 h
- Finish
- All Black
- UL Listed
- Check delivery costs and freight exceptions
- Confirm Doral pickup readiness
- Ships from Miami, FL
- Check this product's warranty terms
Need volume pricing?
Typical applications
- Residential hallways and stairwells
- Boutique hotel guest rooms
- Restaurant and cafe interiors
- Heritage renovation and restoration work
- Light commercial office interiors
A 2-gang, 3-way brass toggle switch on a handmade vintage brass plate finished in all black, measuring 120mm x 120mm with 83.5mm hole spacing. It is intended for residential and light commercial wiring on 120V AC circuits, controlling up to 150W of load per switch. As the plate is handmade, minor chromatic aberration between units is expected. The device is rated 15 A at 120V AC and carries an IP20, non-waterproof environmental rating for dry interior locations. Rated life is 50,000 hours, and shipping weight is 0.5 lb. UL Listed under file number E481372-20200313 and backed by a 1-year warranty.
| Optical | |
|---|---|
| LED Lifetime | 50,000 h |
| Mechanical | |
| Product Dimensions | 120mm*120mm |
| Finish | All Black |
| Material | Brass |
| Weight | 0.5 lb |
| Ordering | |
| Warranty | 1 y |
| Electrical | |
|---|---|
| Operating Voltage | 120 V |
| Maximum Current | 15 A |
| Environmental | |
| IP rating | IP20 |
| Environmental Rating | Non-Waterproof |
| Compliance | |
| Certifications | UL |
| UL File Number | E481372-20200313 |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetCustomer reviews
No reviews yet. Be the first to review this product.
