4-Zone RGB+CCT Panel Remote, 2.4 GHz RF, 30 m Range, Black

The C-5IN1-WP-RGBCCT-4-B is a 4-zone RGB+CCT panel remote designed for use with MiBoxer and Mi-Light 2.4 GHz compatible lighting systems. It provides zone-by-zone control of color, color temperature, brightness, and saturation across up to 16 million color combinations, making it suited for commercial and residential installations requiring precise multi-zone light management. The remote operates on 2 x AAA batteries at 3V DC with a 20 µA standby current draw. It transmits at 6 dBm over the 2400–2483.5 MHz band using GFSK modulation, with a rated control distance of 30 m. The capacitive touch panel is finished in black and supports a working temperature range of -10°C to 40°C. Installation is magnetic, allowing flexible surface mounting without fasteners.
