C-5IN1-WP-5-4Z
4-Zone Capacitive Touch Panel Remote, 2.4GHz RF Wireless, AC 100-240V Input
- 0.2W
Ordered by 29 customers in the last 24 months
- Four independently controlled lighting zones per panel
- 2.4GHz RF link at 6dBm with 30 m specified control distance
- 0.15W standby draw on the AC 100-240V T-series version
- High-precision capacitive touch IC with 1-100% dimming slider
- 86 x 86 x 16mm glass panel, 0.3 lb, wall-mounted installation
Typical applications
- Hotel guest rooms and corridors
- Office and conference room lighting zones
- Retail display and accent lighting
- Residential multi-zone LED systems
- Restaurant and hospitality dining areas
A wall-mounted capacitive touch panel remote for wireless control of compatible smart LED lighting, LED controllers and smart panel controllers. Four independently addressable zones are supported, with T-series (AC-powered) and B-series (battery-powered) versions covering single-channel dimming, CCT tuning, RGB/RGBW and RGB+CCT control. Communication uses the 2.4GHz RF band at 6dBm transmitting power with a specified control distance of 30 meters. Standby power draw on the AC version is 0.15W, and the working temperature range is -10 to 40 degrees C. The glass panel uses a high-precision capacitive touch IC, with a dimming slider covering 1 to 100 percent output and a 60-second delay-off function. Panel size is 86 x 86 x 16mm at 0.3 lb. Supplied with a 1-year warranty.
| Optical | |
|---|---|
| LED Lifetime | 50,000 h |
| Mechanical | |
| Product Dimensions | 86*86*16mm |
| Material | Glass touch panel |
| Mounting | Wall mount |
| Weight | 0.3 lb |
| Electrical | |
|---|---|
| Operating Voltage | 240 V |
| Wattage | 0.15 W |
| Environmental | |
| Ambient Operating Temperature | -10–40 °C(14–104 °F) |
| Ordering | |
| Warranty | 1 y |
Full manufacturer specifications, dimensions and wiring detail.
