9-C2.7-3W-3CCT-D-B
LED Cabinet Puck Light, 3 W 12 V DC, Selectable 3000/4000/6000 K, IP22, Black Finish
- 12V
- 3W
- IP22
Ordered by 53 customers in the last 24 months
- 3 W draw at 12 V DC for low-voltage cabinet circuits
- Selectable 3000 K, 4000 K and 6000 K via touch cover ring
- 85 lm output at 85 lm/W efficacy, 85 CRI
- 68 mm diameter body with 58 mm recess and 10 mm height
- Aluminum shell in black finish, IP22 for indoor use
- Triac, 0-10 V and 1-10 V dimming compatibility
At a glance
- Color Temperature
- 3,000K / 4,000K / 6,000K
- CRI
- 85
- Efficacy
- 85 lm/W
- Beam Angle
- 120°
- Dimmable
- Yes
- Luminous Flux
- 85 lm
- RoHS Compliant
- Free shipping on orders over $300
- Same-day pickup in Doral
- Ships from Miami, FL
- Manufacturer warranty included
Need volume pricing? Ask about wholesale
Typical applications
- Kitchen cabinet and shelf lighting
- Retail display casework
- Millwork and furniture niches
- Closet and wardrobe interiors
- Reception and cabinetry accent lighting
A 2.7 in. recessed LED puck light for cabinetry, shelving and millwork, mounted in a 58 mm recess with an aluminum shell in a black finish. Overall size is 68 mm diameter by 10 mm high, allowing installation in shallow furniture panels. The fixture draws 3 W at 12 V DC and delivers 85 lm at an efficacy of 85 lm/W, with an 85 CRI output and a 120-degree beam angle. Color temperature is selectable between 3000 K, 4000 K and 6000 K, and on/off, dimming and CCT selection are handled through the touch cover ring. Rated life is 50,000 hours. Dimming is compatible with triac, 0-10 V and 1-10 V control when matched with a dimmable transformer and dimmer. RoHS compliant, with a 2-year warranty. IP22 rated for indoor use.
| Optical | |
|---|---|
| Luminous flux | 85 lm |
| Efficacy | 85 lm/W |
| CCT | 3,000K / 4,000K / 6,000K |
| Selectable CCT | Yes |
| CRI | 85 |
| Beam angle | 120° |
| LED Lifetime | 50,000 h |
| Color | Black |
| Environmental | |
| IP rating | IP22 |
| Electrical | |
|---|---|
| Operating Voltage | 12 V |
| Wattage | 3 W |
| Dimmable | Yes |
| Dimmer Type | Triac + 0-10V |
| Mechanical | |
| Product Dimensions | 68 mm dia. x 10 mm H, 58 mm recess |
| Finish | Black |
| Material | Aluminum (shell) |
| Mounting | Recessed in furniture |
| Ordering | |
| Warranty | 2 y |
Full manufacturer specifications, dimensions and wiring detail.
