8-T8x2-5-D36-5K-F
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
Ordered by 10 customers in the last 24 months
The Lumipro D2 Series 5 ft Integrated LED Tube (8-T8x2-5-D36-5K-F) is a double-row, frosted-lens tube fixture designed for commercial and institutional interiors. Built on an aluminum heat sink with a PC diffuser, it is suited for offices, warehouses, schools, hospitals, retail spaces, and similar applications requiring uniform ambient illumination. The fixture operates at 36W on AC 100–277V (50/60 Hz) and delivers 4,680 lumens at 5000K CCT with a CRI of 80 and a 120-degree beam angle, yielding an efficacy of 130 lm/W. The double-row SMD2835 LED array provides wide, even light distribution. Power factor exceeds 0.95, THD is 20% or below, and the rated operating life is 50,000 hours. Operating temperature range is -20°C to 45°C, and the fixture contains no mercury. The D2 Series carries RoHS compliance. The manufacturer offers a 30-day limited warranty on select configurations; buyers should confirm applicable warranty terms at time of purchase.
| Optical | |
|---|---|
| Luminous flux | 4,600 lm |
| CCT | 5,000 K |
| CRI | 80 |
| Beam angle | 120° |
| LED Lifetime | 50,000 hours |
| Ordering | |
| Warranty | 30 days |
| Electrical | |
|---|---|
| Operating Voltage | AC 100–277V |
| Wattage | 36 W |
| Mechanical | |
| Product Dimensions | 59.25 x 1.38 x 1.30 |
| Environmental | |
| IP rating | IP20 |
| Ambient Operating Temperature | -20 to 45 |
Full manufacturer specifications, dimensions and wiring detail.
Download datasheetNo reviews yet. Be the first to review this product.
Need volume pricing? Ask about wholesale
Total for 1 item
$17.03
Based on real order history
Order history does not verify compatibility. Check voltage, strip width, pins and load before selecting parts.
