P-S200-24-ETL
200W 24VDC IP67 Waterproof LED Power Supply, 100–130VAC Input
- 200W maximum output at 24VDC constant voltage
- 8.5A maximum output current with power factor above 0.6
- IP67 sealed aluminum alloy enclosure in black finish
- 100–130VAC input at 50/60Hz, ETL listed
- Working temperature range of -30°C to 50°C
- Short circuit, overload, overvoltage and overtemperature protection
- Retiro el mismo día en Doral
Constant-voltage, IP67-rated waterproof LED power supply in an ultra-thin aluminum alloy housing, intended for indoor and outdoor LED lighting installations in dry, wet and rain-exposed locations. The unit delivers up to 200W at 24VDC with a maximum output current of 8.5A. Input accepts 100–130VAC at 50/60Hz with a typical efficiency of 89% and power factor greater than 0.6. Ripple and noise measure 240mV or less, and the working temperature range is -30°C to 50°C at 20–99%RH. Protections cover short circuit, overload, overvoltage and overtemperature, each with automatic recovery. Case size is 238 x 58 x 32mm with 250mm AC and DC leads. The power supply is ETL listed under UL file 5024093 and carries a 3-year warranty.
