200W 24VDC Dimmable Waterproof LED Driver, IP67, 5-in-1 Dimming, UL Listed

The P-S200-24-D-UL is a constant-voltage LED driver designed for outdoor and wet-location lighting installations. It delivers 24VDC output at up to 200W and 8.5A, supporting 5-in-1 dimming compatibility: 0-10V, 1-10V, 10V PWM, Triac, and Resistance dimming. The driver is suited for use in commercial and architectural lighting systems requiring flexible dimming control. The driver accepts an AC input range of 100-130Vac or 175-264Vac at 50/60Hz and operates across an ambient temperature range of -30°C to 50°C. Typical efficiency is rated at 90%, and the unit is rated for up to 50,000 hours of service life. Dimming range spans 0-100% with LED start possible at 1%, and output is flicker-free. Protections include overload, over-temperature, short circuit, and over-voltage. The unit is cooled by free air convection and measures 238 x 58 x 32mm. The driver carries an IP67 ingress protection rating, confirming full dust-tight construction and protection against temporary water immersion. The unit is UL Listed (E498189) and complies with IEC/EN61347-1 and IEC/EN61347-2-13 safety standards. A 3-year warranty is included.
