SKU: 5-LDW1213
The 5-LDW1213 is a trimless drywall aluminum LED profile designed for recessed linear lighting installations in both residential and commercial applications. Its trimless construction integrates flush with drywall surfaces, eliminating the need for visible trim hardware and producing a clean, minimalist appearance. The profile measures 52x13mm and is finished in anodized silver. Constructed from 6063-T5 aluminum with a high-standard anodized surface treatment, the profile provides both heat dissipation and physical protection for LED strip installations. It accommodates flexible LED strips up to 9mm in width and is available in lengths up to 13.2ft (4m). The standard milky (opal) PC diffuser transmits 86% of light with medium coefficient diffusion, delivering uniform brightness while reducing visible LED hotspots. Operating temperature range is -50°C to 100°C. Diffuser options include transparent, milky/opal, and black; profile finish options include silver anodized, white painted, and black anodized.
