P-S300-C2-UL
Class 2 Constant Voltage LED Driver, 12VDC 300W, 5-Channel, 120-277VAC, IP67
- 300W
- IP67
Ordered by 6 customers in the last 24 months
- 300W constant voltage output on five 5A channels at 12VDC
- Universal 120-277VAC input across a 47-63Hz frequency range
- Active PFC with 0.99 typical power factor and THD below 20%
- IP67 metal enclosure rated NEMA 4X for dry, damp, and wet locations
- Triac forward and reverse phase, MLV and ELV dimming modes
- UL and cUL listed to UL8750 and UL1310, FCC Part 15 Class B
At a glance
- Dimmable
- Yes
- LED Lifetime
- 50,000 h
- Wattage
- 300 W
- Maximum Current
- 3.3 A
- Power Factor
- 0.95
- Dimmer Type
- Triac forward phase, reverse phase, MLV, ELV
- UL Listed
- FCC
- Free shipping on orders over $300
- Same-day pickup in Doral
- Ships from Miami, FL
- Manufacturer warranty included
Need volume pricing? Ask about wholesale
Typical applications
- Outdoor channel letter and moving sign installations
- Exterior architectural and facade LED strip lighting
- Commercial linear lighting and wall washer runs
- Parking structure and canopy LED fixtures
- Landscape and site lighting enclosures
The P-S300-C2-UL is a 12VDC, 300W constant voltage LED driver configured with five independent 5A output channels for commercial LED lighting and moving sign applications. The universal 120-277VAC input and IP67-rated metal enclosure suit dry, damp, and wet locations in both indoor and outdoor installations. Typical efficiency at full load reaches 88% at 120VAC and 89% at 277VAC. Built-in active PFC yields a 0.99 power factor at 120VAC with THD below 20%, while output is held to ±0.5V tolerance and ±1% load regulation across a 0.01-100% load range. Operation is flicker-free from -40°C to +60°C, with short-circuit, overload, and over-temperature protection that recovers automatically. UL and cUL listed to UL8750 and UL1310, FCC Part 15 Class B, Type HL and NEMA 4X rated, and Title 24 JA8 compliant. A 7-year warranty is provided.
| Optical | |
|---|---|
| LED Lifetime | 50,000 h |
| Mechanical | |
| Product Dimensions | 304.4*78*46mm |
| Finish | Grey |
| Material | Metal |
| Weight | 3.97 lb |
| Environmental | |
| IP rating | IP67 |
| Environmental Rating | Waterproof |
| Ambient Operating Temperature | -40 °C(-40 °F) |
| Operating Humidity | 20-90% RH, non-condensing |
| Ordering | |
| Warranty | 7 y |
| Electrical | |
|---|---|
| Wattage | 300 W |
| Maximum Current | 3.3 A |
| Power Factor | 0.95 |
| Dimmable | Yes |
| Dimmer Type | Triac forward phase, reverse phase, MLV, ELV |
| Power Supply Input | 120-277VAC |
| Power Supply Output | 300 |
| Input Connection Type | Hardwired leads, black/white line and neutral with green ground |
| Compliance | |
| Certifications | UL |
| UL File Number | E525847 |
Full manufacturer specifications, dimensions and wiring detail.
