C-AM5-720
RGBCCT 5-Channel LED Amplifier, 720W Max, 12/24V, 30A Output
Shipping options and charges are confirmed at checkout. Freight quotes are shown separately. Contact the showroom to confirm branch stock before visiting.
- 24V
- 150W
- Five output channels for RGBCCT strip and fixture runs
- Output rated to 720W at 24V, 360W at 12V, 150W at 5V
- Maximum output current of 30A across all channels
- PWM input signal accepted from DC 5V to DC 24V
- Dimming range of 0.1% to 100% passed through to the load
- Screw terminals with 7mm caliber in common anode mode
At a glance
- Product Dimensions
- 147mm L x 70mm W x 34mm H
- Maximum Current
- 30 A
- Dimmable
- Yes
- Dimmer Type
- PWM signal, 0.1%-100% dimming range
- Input Connection Type
- Screw terminal, 7mm caliber, common anode
- Material
- Aluminum
- Check delivery costs and freight exceptions
- Confirm Doral pickup readiness
- Ships from Miami, FL
- Check this product's warranty terms
Need volume pricing?
Typical applications
- Architectural cove and perimeter lighting runs
- Retail and hospitality RGBCCT strip installations
- Commercial facade and signage lighting
- Long-run LED tape in lobbies and atriums
A 5-channel RGBCCT LED signal amplifier in an aluminum housing, used to repeat and extend PWM dimming signals across large-scale LED strip and fixture runs. It is applied in commercial and architectural installations where a single controller cannot carry the full load of an RGBCCT run. Working voltage is DC 5V, 12V or 24V, with output power rated below 150W at 5V, 360W at 12V and 720W at 24V. Maximum output current is 30A. The unit accepts a PWM input signal from DC 5V to 24V and supports a dimming range of 0.1% to 100%. Wiring uses screw terminals with a 7mm caliber in common anode connection mode. Dimensions are 147mm (L) x 70mm (W) x 34mm (H).
| Electrical | |
|---|---|
| Operating Voltage | 24 V |
| Wattage | 150 W |
| Maximum Current | 30 A |
| Dimmable | Yes |
| Dimmer Type | PWM signal, 0.1%-100% dimming range |
| Input Connection Type | Screw terminal, 7mm caliber, common anode |
| Mechanical | |
|---|---|
| Product Dimensions | 147mm L x 70mm W x 34mm H |
| Material | Aluminum |
Full manufacturer specifications, dimensions and wiring detail.
