300W 24V DC Dimmable LED Driver, Triac & 0-10V, 100-130VAC, IP20

The P-300S-24-D-ETL is a 300W constant-voltage LED driver with 24V DC output, designed for commercial and architectural LED lighting installations requiring dimming control. It accepts 100–130VAC input and supports both Triac and 0/1–10V dimming protocols, making it compatible with a wide range of dimming systems and controllers. The driver delivers a rated output current of 12.5A at 300W with a voltage tolerance of ±0.5V and typical full-load efficiency of 86%. Ripple and noise is rated at 250mVp-p. The unit is rated IP20 for dry indoor environments and operates across an ambient temperature range of -20°C to +50°C. Short-circuit protection operates in hiccup mode with automatic recovery, and over-temperature shutdown activates at 100°C ±10°C. Dimensions are 295 × 60 × 30mm with a weight of 0.52kg. The driver carries an ETL listing and CE mark. A 100% full-load burn-in test is performed at the factory. The product is backed by a 3-year warranty. As a component-level device, the final equipment installer is responsible for re-qualifying EMC compliance within the complete installation per applicable directives.
