Knuckle Mount Bracket, 1/2 in. Trunnion, SECC Steel, for 150W Watt-Selectable Floodlight

The F-S-S150W-KM is a 1/2 in. knuckle mount bracket built for the F-S150W-3CCT-UL watt-selectable floodlight. It provides an adjustable mounting interface for locating the floodlight on poles, walls, parapets and other structural supports in commercial and industrial installations. The bracket is formed from SECC electrogalvanized steel and follows the FL05 universal 1/2 in. rotating shaft geometry, allowing the luminaire to be aimed and locked in position after installation. Overall drawing envelope measures 124.5 by 123 by 69.6 mm, with manufacturing tolerances held to ±0.4 mm across the 50 to 200 mm dimensional range.
