9-LP-Z-CNT-I
Buckle Joint Connector for 9-LP Linear Light, I-Type Continuous Run
- Kit includes one I-connector, one spring buckle and two screws
- Mechanically links 9-LP linear fixtures end-to-end in continuous runs
- Spring buckle secures across the connection plate of the adjoining fixture
- Wiring passed between sections with quick connectors during joining
- Removable and reattachable for maintenance access to the fixture body
- Matched to 9-LP fixtures rated at 50,000 hours with a 1-year warranty
- Retiro el mismo día en Doral
- Envíos desde Miami, FL
- Garantía del fabricante incluida
The 9-LP-Z-CNT-I Buckle Joint Connector is a mechanical joining component designed for continuous-run installations of the 9-LP linear architectural light fixture, I-type configuration. The kit includes one I-connector, one spring buckle, and two mounting screws, allowing adjacent fixture sections to be mechanically linked end-to-end. Installation involves lifting the top cover, removing the magnetic end caps, inserting the I-connector into the fixture ends, securing with the provided screws if required, and snapping the spring buckle across the connection plate of the adjoining fixture. Fixture power cords are routed between sections and joined with quick connectors. The connector is removable and reattachable, supporting maintenance access without damaging the fixture assembly. Supplied for use with 9-LP fixtures rated at 50,000 hours and covered by a 1-year warranty.
