SKU: CAJ2-12-100
The CAJ2-12-100 is a 16 AWG, 2-conductor parallel hook-up wire supplied in a 50 ft (15.2 m) roll. Conductors are color-coded red and black for polarity identification, making it suitable for low-voltage DC wiring, LED driver connections, control circuits, and general-purpose hook-up applications in commercial and light industrial installations. The wire is rated for 300V and 80°C continuous operating temperature. Each conductor uses a 26/0.24TS stranded copper construction with a nominal sectional area of 1.18 mm². Both insulation and jacket are PVC. The parallel flat profile measures 6.2 mm overall diameter per the datasheet for the 16 AWG configuration. The cable is listed under UL2468.
