16 AWG 2-Conductor Red/Black Hook-Up Wire, UL2468, 300V, 50 ft Roll

The CAJ2-12-100 is a 16 AWG, 2-conductor parallel hook-up wire supplied in a 50 ft (15.2 m) roll. Conductors are color-coded red and black for polarity identification, making it suitable for low-voltage DC wiring, LED driver connections, control circuits, and general-purpose hook-up applications in commercial and light industrial installations. The wire is rated for 300V and 80°C continuous operating temperature. Each conductor uses a 26/0.24TS stranded copper construction with a nominal sectional area of 1.18 mm². Both insulation and jacket are PVC, with a black jacket over red and black conductors, and the assembly carries an IP44 rating. The parallel flat profile measures 6.2 mm overall diameter per the datasheet for the 16 AWG configuration. The cable is listed under UL2468. The product is CE marked and RoHS compliant, and is covered by a 1-year warranty.
