CA3J-12-15
12AWG, 3P wire cable with black silicone jacket ,300V, 50 ft per roll, cable colors color:black/white/green, UL Listed
- 12 AWG stranded copper, 47/0.3 mm conductor construction
- 300 V rating verified by 2000 V one-minute withstand test
- Rubber sheath with cotton yarn filling, 105 C rated
- Finished outside diameter of 11.2 +/-0.2 mm
- Conductor resistance not greater than 5.5 ohm/km
- Black, white and green core identification on 12 m rolls
De un vistazo
- LED Lifetime
- 50,000 h
- Operating Voltage
- 300 V
- Wire Gauge
- 12 AWG
- Product Dimensions
- 11.2 +/-0.2 mm outside diameter
- Length
- 12 m
- Finish
- Black
- Envío gratis en pedidos de más de $300
- Retiro el mismo día en Doral
- Envíos desde Miami, FL
- Garantía del fabricante incluida
Aplicaciones típicas
- Portable tool and equipment leads
- Machine and motor power drops
- Temporary jobsite power distribution
- Stage and event production power runs
- Industrial control panel feeds
SJOOW 12 AWG 3-conductor portable cord supplied on 12 m rolls for equipment feeds, machine drops, portable tool leads and temporary power runs where a flexible rubber-jacketed cable is required. Conductors are color coded black, white and green for line, neutral and ground identification. The cable is rated 300 V at 105 C with a finished diameter of 11.2 +/-0.2 mm. Conductor construction is 47/0.3 mm stranded copper with conductor resistance not greater than 5.5 ohm/km. Insulation averages at least 0.76 mm and the rubber sheath averages at least 1.14 mm, with cotton yarn filling in the interstices. The cord is non-waterproof and intended for dry and protected routing.
| Óptica | |
|---|---|
| Vida útil del LED | 50,000 h |
| Mecánica | |
| Dimensiones | 11.2 +/-0.2 mm outside diameter |
| Largo | 12 m(39.4 ft) |
| Acabado | Black |
| Material | Rubber jacket with cotton yarn filling |
| Eléctrica | |
|---|---|
| Voltaje de operación | 300 V |
| Calibre del cable | 12 AWG |
| Ambiental | |
| Clasificación ambiental | Non-Waterproof |
| Temperatura ambiente de operación | 105 °C(221 °F) |
Especificaciones completas del fabricante, dimensiones y detalle de conexión.
