CA3-12-20
Flat Ribbon Cable, 12 AWG 3-Conductor, 300V, 80°C Tinned Copper, 20 ft Roll
- 12 AWG conductors in a three-wire flat ribbon configuration
- Tinned stranded copper conductor for solder and crimp terminations
- 300V rated PVC insulation with 80°C conductor temperature rating
- Color-coded white, red and yellow for circuit identification
- 2000V AC per minute dielectric withstand test
- Supplied in 20 ft (6 m) rolls, RoHS 1.0 six-substance compliant
- Retiro el mismo día en Doral
- Envíos desde Miami, FL
- Garantía del fabricante incluida
The CA3-12-20 is a 12 AWG, 3-conductor flat ribbon cable supplied in 20 ft (6 m) rolls. Conductors are color-coded white, red, and yellow, making polarity identification straightforward during installation. This cable is suited for LED sign wiring, power distribution runs, and similar commercial or industrial low-voltage applications where a compact, flat profile is required. The cable is rated at 300V and 80°C. Conductors are tinned stranded copper with PVC insulation. Insulation passes a 2000V AC dielectric test and meets a minimum tensile strength of 10.3 MPa with 100% elongation retention prior to aging. Insulation materials comply with RoHS 1.0 (6-substance) environmental requirements.
