7-57x3W-3K-UL

LED Sign Module, SMD2835 3-LED, 1.32 W, 3000 K, 12 VDC, IP65, 160-Degree Beam, UL Listed

USD 30.00

12V
1,3W
IP65

Disponible — 4940 disponibles

Three SMD2835 emitters producing 110 lm per module at 3000 K
Clear optic lens with 160-degree beam for even cabinet coverage
12 VDC constant-voltage input, 1.32 W per module
IP65 injected PVC housing rated -25 C to +60 C
UL Listed under file E348340, plus CE and RoHS
CRI 75 and 50,000-hour rated LED life

Retiro el mismo día en Doral
Envíos desde Miami, FL
Garantía del fabricante incluida

An injection-molded PVC LED sign module built on three SMD2835 emitters, intended as backlighting for illuminated channel letters, light boxes and cabinet signage with depths of 60 mm to 180 mm. Modules ship 20 per string and are located with 3M tape, then secured with screws or neutral silicone adhesive. Each module operates on 12 VDC constant voltage at 1.32 W and delivers 110 lumens at 3000 K with a CRI of 75 and a clear 160-degree optic lens. Rated LED life is 50,000 hours. The IP65 housing measures 80 x 18 x 5.8 mm and operates from -25 C to +60 C. CE, RoHS and UL Listed under file E348340. Warranty is 3 years. Installation and maintenance should be performed by qualified personnel.
